The multi-piece combination structure is suitable for processing solid wood mortise and tenon grooves and connecting parts grooves of panel furniture. The groove width can be adjusted from 3 to 12mm, which can meet different process requirements such as dovetail mortise and tenon and eccentric wheel holes.
GROOVING SAW BLADE FREATURES:
The combination of main saw and 2-4 spacer plates supports stepped tooth slotting.
The spacer plates are plated with hard chromium (Cr), and the wear resistance is improved by 60%.
Center hole shock-absorbing gasket to reduce slotting vibration noise;
The temperature rise should be no more than 40℃ after continuous operation for 8 hours.
We can provide customized services according to your detailed specifications or drawings. If you are interested in our Grooving saw blades, please request a quotation for more information (such as minimum order quantity, price, delivery time, etc.). Our sales staff and engineers will contact you as soon as possible after the quotation and provide you with a tailor-made solution.
| Diameter | Teeth Width | Body Thickness | Inner Dia | No. of Teeth |
| 120 | 3.0/4.0 | 2.2 | 20/22 | 24 |
| 125 | 3.0/4.0 | 2.2 | 20/45 | 24 |
| 125 | 3.3/4.3 | 2.5 | 22 | 24 |
| 150 | 3.3/4.3 | 2.5 | 25.4/45 | 36 |
| 150 | 3.3/4.3 | 2.5 | 25.4/45 | 40 |
| 150 | 4.3/5.3 | 3.2 | 25.4/45 | 36/40 |
| 160 | 3.3/4.3 | 2.5 | 22 | 24 |
| 160 | 3.3/4.3 | 2.5 | 25.4/30 | 36 |
| 160 | 3.3/4.3 | 2.5 | 25.4/30 | 40 |
| 160 | 4.3/5.3 | 3.2 | 45/55/60 | 36 |
| 180 | 3.3/4.3 | 2.5 | 25.4/30 | 36 |
| 180 | 3.3/4.3 | 2.5 | 25.4/30 | 40 |
| 180 | 3.3/4.3 | 3.2 | 30 | 36 |
| 180 | 4.3/5.3 | 3.2 | 30/50 | 36 |
| 180 | 4.3/5.3 | 3.2 | 30/50 | 40 |
| 200 | 4.3/5.3 | 3.2 | 30/45 | 40 |
| 200 | 4.3/5.3 | 3.2 | 20/80 | 36 |
| 200 | 4.6/5.6 | 3.5 | 20/65 | 36 |
Q1: what is the advantage of your products?
A1: We are professional manufacturer in this field with lots of years R& D and market research experience, we can provide competitive price and high quality products for you
Q2: How is your quality?
A2: We have a very seriously control system( 9001 and SGS product quality control) and 100% QC inspection Before Shipment.
Q3: Payment
A3: TT, L/ C, Paypal and Western Union and other payment methods. The payment range comes from different countries and regions
Q4: What are the way of the transportation?
A4: Depending upon the weight of goods we can transfer by express, and shipping, including DHL UPS. TNT and FEDEX
Q5: Can we make OEM or ODM? / Can we put customer brand?
A5: Yes, we can make the OEM and ODM for you if your quantity is large, customer logo, color, shape, package method should be provided by the customer.
