wood panel sizing blade suitable for fixed-length and fixed-width cutting of solid wood, multi-layer boards and density boards, and is an ideal choice for standardized production of furniture boards. It can simultaneously meet the requirements of longitudinal and transverse cutting, with a cutting accuracy of ±0.1mm.
WOOD PANEL SCIZING BLADE FEATURES:
100T-120T ultra-dense tooth configuration reduces chipping of thin plates.
Negative rake Angle tooth profile design enhances edge flatness;
Titanium TiN coating, enhancing wear resistance and corrosion resistance;
Central hole shock absorption ring to reduce vibration during high-speed operation.
We can provide customized services according to your detailed specifications or drawings. If you are interested in our wood panel sizing blades, please request a quotation for more information (such as minimum order quantity, price, delivery time, etc.). Our sales staff and engineers will contact you as soon as possible after the quotation and provide you with a tailor-made solution.
| Diameter | Teeth Width | Body Thickness | Inner Dia | No. of Teeth |
200 | 3.2 | 2.2 | 30 | 48 |
250 | 3.2 | 2.2 | 30 | 60 |
300 | 3.2 | 2.2 | 30 | 60 |
300 | 3.2 | 2.2 | 30 | 72 |
300 | 3.2 | 2.2 | 30 | 80 |
300 | 3.2 | 2.2 | 30 | 96 |
320 | 3.2 | 2.2 | 25.4/30 | 120 |
350 | 3.2 | 2.2 | 25.4/30 | 100 |
350 | 3.2 | 2.2 | 25.4/30 | 120 |
350 | 3.5 | 2.5 | 30 | 72 |
350 | 3.5 | 2.2 | 30 | 84 |
350 | 3.2 | 2.5 | 30 | 96 |
400 | 3.5 | 2.5 | 30 | 60 |
400 | 3.5 | 2.5 | 30 | 84 |
400 | 3.5 | 2.5 | 30 | 96 |
Q1: what is the advantage of your products?
A1: We are professional manufacturer in this field with lots of years R& D and market research experience, we can provide competitive price and high quality products for you
Q2: How is your quality?
A2: We have a very seriously control system( 9001 and SGS product quality control) and 100% QC inspection Before Shipment.
Q3: Payment
A3: TT, L/ C, Paypal and Western Union and other payment methods. The payment range comes from different countries and regions
Q4: What are the way of the transportation?
A4: Depending upon the weight of goods we can transfer by express, and shipping, including DHL UPS. TNT and FEDEX
Q5: Can we make OEM or ODM? / Can we put customer brand?
A5: Yes, we can make the OEM and ODM for you if your quantity is large, customer logo, color, shape, package method should be provided by the customer.
